PFE Advanced 20 Outputs A new star has been added to the product range and is already shining bright in the galaxy: PFE Advanced 20 Outputs Please follow this link for more details and many pictures: https://www.firing-system.com/project/pfe-advanced-20-outputs These options are available for an extra charge: – Stepping function – Sleep function – Terminal function…
Highlights Absolutely waterproof (Standard IP65, if breather is replaced with a sealed screw IP67) Framed flat gaskets with large sealing surface Extremely robust and thick-walled aluminium housing All outputs can be programmed without any restrictions Fully integrated wireless solution Brilliant display with menu in plaintext Bi-directional communication and programming Measures and displays the precise resistance…
The firing outputs of the PFE Advanced 10 and 20 Outputs can directly drive magnetic valves (also called solenoids). The coil of every magnetic valve is an inductive load. Every inductive load creates a high voltage peak when it is switched off. This is called self-inductance. This voltage peak has the opposite polarity of the…
Update Details Feature: Hardware checks at power-up (memory check, sensor checks, radio module check, data integrity checks), with corresponding error messages in the display. Feature: Enable/disable device via radio command implemented. The devices can now be enabled or disabled at the PFC by a new menu. If a device has been disabled, incoming firing commands…
Upgrade Details The firmware of the PFE Advanced 10/100 Outputs has been strongly developed recently and especially the new delay parameter for the Terminal function leads to the fact that the memory chip for the non-volatile values, also called EEPROM, is no longer sufficient for older devices. If old devices with installed Terminal function…
Update Details Feature: Hardware checks at power-up (memory check, sensor checks, radio module check, data integrity checks), with corresponding error messages in the display. Feature: The request for the output details of all five outputs in the remote device access from the PFC Advanced and the Composer has been significantly accelerated. When updating PFE Advanced…
Update Details Feature: Hardware checks at power-up (memory check, sensor checks, radio module check, data integrity checks) with corresponding error messages in the display. Feature: The request for the output details of a group of ten outputs in the remote device access from the PFC Advanced and the Composer has been significantly accelerated. Feature: Enable/disable…
Update Details The firmware of the device has been strongly developed in the last months and numerous useful new functions and improvements have been implemented: Feature: Various automatic hardware and configuration checks added with corresponding error messages in the display at power-up (memory check, data integrity checks). Added detection and warning message in case of…
Highlights Slim, high flames with low wind sensitivity and lowest possible fallout Integrated pressure accumulater buffers pressure fluctuations Operation with Isopar L, IPA or Ethanol Three control options: wired DMX, wireless DMX and optional Galaxis Advanced Radio Module For DMX (radio or cable) there is an input and output at the Pump Station with looping…
Highlights Up to three Flame Heads can be connected No mains power required, thanks to integrated battery solution with up to 90 h standby time DMX input and output with loop-through of the signal to up all Flame Heads and additional devices Rugged, power coated aluminum housing, protected against rainwater Operation with Isopar L, IPA…
